Reducers have the same quality and performance
as all the hydraulic engines line. They have
been especially developed in order to be easily
assembled to hydraulic engines. For these
purpose, they were adapted by reducing the
shaft so that it becomes the pinion shaft
of the planetary gearbox. In this way, shaft
stress is considerably reduced by the coupling
system. The torque is multiplied by the relation
between the transmission and the divided speed.
They produce a silent and swift motion at
low speed. Thanks to the little maintenance
it needs and its reduced size, they provide
a high durability and a low cost. The moment
a reducer is installed, please observe the
following recommendations: place the drainage
top at the highest position. Pour the amount
of oil indicated in the charts. After the
first twenty hours, change said oil for new
oil and repeat this procedure approximately
every one thousand hours. Check that the oil
temperature does not exceed 70ºC. In
case of doubt, make a technical consult as
soon as possible.
