For decompression. Line assembly, Size 3/8”,
3/4” NPT and 1” 1/4 BSPT
The exhaust valves by decompression are used
in a system where it is be necessary to produce
a fluid exhaust or block in that section,
without requiring the equipment pressure.
The more typical cases in which they are applied
are the following:
Pump exhaust in a high and low circuit, simple
effect cylinder descent without having the
equipment in motion, activate or deactivate
part of the system.
- Multiple accessories in order to
activate it manually or automatically.
- They are supplied in four manufacturing
sizes:
VF-L-32 with connection screws 3/8”
NPT.
VF-L-50 with connection screws 1/2”
NPT.
VF-L-75 with connection screw 3/4” NPT.
VF-L-125 with connections screw 1" 1/4
BSPT.
- Maximum working pressure: 210 kg/cm².
