Line
assembly. Models 32, 50 and 75. Sizes 3/8",
1/2" and 3/4" NPS.
These valves have a wide scope of usage,
where no hydrostatic or thermal compensation
is required.
Axial construction valves have one-way and
two-way regulation. They are particularly
suitable for being used where a compact
assembly in small-sized places is required.
- - Two sizes:
VRC-32, connection 3/8” NPS
VRC-50, connection 1/2” NPS
VRC-75, connection 3/4” NPS
- Suitable to operate with flow volumes up
to 30 l/min., 50 l/min. and 120 l/min. respectively.
- Maximum pressure of 320 Kg/cm².
