With
thermal and bar pressure compensation. Uni-directional
and bi-directional regulation. Board assembly.
Models 32 and 75. Sizes 3/8" and 3/4"
NPT.
These valves are used where it is necessary
to keep a constant flow volume, regardless
of the value acquired by the actuator load
and/or the fluid temperature. Their main
usage scope lies within the control advance
of machines-tools, with uni-directional
and bi-directional regulation.
- - Two sizes in two different versions 3/8"
and 3/4”, uni-directional and bi-directional.
VCF-32 up to 32 l/min.
VCF-32-R up to 32 l/min.
VCF-75 up to 106 l/min.
VCF-75-R up to 106 l/min.
- Maximum pressure 210 Kg/cm².
