Uni-directional.
Line assembly. Models 100, 125 and 150. Sizes
1” NPT, 1” 1/4 and 1” 1/2
BSPT.
This valve is used to control the activation
speed of an actuator. Activating it allows
to change the flow volume in one direction,
enabling the free flow in the opposite direction.
The regulation of the fluid passage is performed
manually by means of a wheel-type tap.
- - Three models:
VRR-100-110 l/min.
VRR-125 -150 l/min.
VRR-150 – 250 l/min.
- Three types of connections:
VRR-100 – 1”NPT.
VRR-125 – 1”1/4 BSPT.
VRR-150 – 1”1/2 BSPT.
- Maximum work pressure: 210 kg/cm2.
- Viscosity: 10 to 200 CST.
- Temperature: -10 to +75 ºC.
